CJX8(B)AC Contactor


Application
CJX8(B) series AC Contactors are mainly used in 50/60 Hz electrical lines with the rated voltage up to 660V AC and rated current up to 475A, and they are applicable for remote making and breaking of electrical lines or frequently controlling of AC motors, without voltage protection. Usually, it can be combined with T series thermal relay to form electromagneticstarters which have overload and open-phase protection. It complies with IEC 947-4.
Specifications
Type
B9
B12
B16
B25
B30
B37
B45
B65
B85
B105
B170
B250
B370
The highest control power(kw)
220V
2.2
3
4
6.5
9
10
13
16
20
28
46
60
32
380V
4
5.5
7.5
11
15
18.5
22
33
45
55
90
132
200
500V
4
5.5
7.5
11
15
18.5
22
40
50
75
110
160
250
660V
4
5.5
5.5
11
15
18.5
22
40
50
75
110
160
250

rated herting current Ith(A)
16
20
25
40
45
45
60
80
100
140
230
300
400
rated working current AC2/AC3/AC4

380V

660V
8.5
11.5
15.5
22
30
37
44
65
85
105
170
245
370
3.5
4.9
6.7
13
17.5
21
25
45
55
82
118
170
268
Rated holding power of a holding coil/pull-in(VA/W)

9/2.2

60/50

9/2.2

60/50

9/2.2

60/50

10/3

85/65

10/3

85/65

22/5

175/125

22/5

125

30/8

270/130

30/8

270/130

32/9

510/280

60/15

790/460

66/16

1100/600

100/27

900/350
CA7
CA9-11 CA9-20
CA11-11 CA-20
B9,B12,B16,B25,B30,B37
B45,B65,B85,B105
B170,B250,B370
TP Type pneumatic timer delaying the operation of next stage of a control loop
Start delay
TPD40 0.3-40s
Relief delay
TP140 0.3-40s
TP1180 10-180S
TPD180 10-180s
Type
UA-AX422
UA-AX431
UA-AX440
UA-AX413
UA-AX404
NO
2
3
4
1
0
NC
2
1
0
3
4

Type
UA-AX211
UA-AX220
UA-AX202
UA-AX2
UA-AX4
NO
1
2
0
NC
1
0
2
