LR1
Thermal Relay
|
|
|
Application LR1-D series thermal relay is suitable for thermal
protection in the circuit with AC 50or 60Hz, voltage up to 660V,
motor power up to 45KW or less. It has differential attachment and
automatic temperature-compensating function. It can be fixed on
to contactor and canalso be fixed independently. |
| Specifications | |||||||
|
Type
|
Adjusting range of current(A)
|
Control power(AC3)(KW)
|
Plug in contactor
|
||||
|
220V
|
380V
|
415V
|
440V
|
660V
|
LC1-D09-25
|
||
|
LR1-D 09301
|
0.1กซ0.16
|
LC1-D09-25
|
|||||
|
LR1-D 09302
|
0.16กซ0.25
|
LC1-D09-25
|
|||||
|
LR1-D 09303
|
0.25กซ0.40
|
LC1-D09-25
|
|||||
|
LR1-D 09304
|
0.40กซ0.63
|
0.37
|
LC1-D09-25
|
||||
|
LR1-D 09305
|
0.63กซ1
|
0.55
|
LC1-D09-25
|
||||
|
LR1-D 09306
|
1กซ1.6
|
0.37
|
0.55
|
0.7กซ1.1
|
LC1-D09-25
|
||
|
LR1-D 09307
|
1.6กซ2.5
|
0.37
|
0.55กซ0.75
|
1.1
|
0.75กซ1.1
|
1.5
|
LC1-D09-25
|
|
LR1-D 09308
|
2.5กซ4
|
0.55กซ0.75
|
1.1กซ1.5
|
1.5
|
1.5
|
2.2กซ3
|
LC1-D09-25
|
|
LR1-D 09310
|
4กซ6
|
1.1
|
2.2
|
2.2
|
2.2
|
4
|
LC1-D09-25
|
|
LR1-D 09312
|
5.5กซ8
|
1.5
|
3
|
3กซ3.7
|
3กซ3.7
|
5.5
|
LC1-D09-25
|
|
LR1-D 09314
|
7กซ10
|
2.2
|
4
|
4
|
4
|
7.5
|
LC1-D09-25
|
|
LR1-D 12316
|
10กซ13
|
3
|
5.5
|
5.5
|
5.5
|
10
|
LC1-D09-25
|
|
LR1-D 16321
|
13กซ18
|
4
|
7.5
|
9
|
9
|
15
|
LC1-D09-25
|
|
LR1-D 25322
|
18กซ25
|
5.5
|
11
|
11
|
11
|
18.5
|
LC1-D09-25
|
|
LR1-D 40353
|
23กซ32
|
7.5
|
15
|
15
|
15
|
22
|
LC1-D04กข50กข60
|
|
LR1-D 40355
|
30กซ40
|
10
|
18.5
|
22
|
22
|
30
|
LC1-D04กข50กข60
|
|
LR1-D 63357
|
38กซ50
|
11
|
22
|
25
|
25
|
37
|
LC1-D04กข50กข60
|
|
LR1-D 63359
|
48กซ57
|
15
|
25
|
30
|
30
|
45
|
LC1-D04กข50กข60
|
|
LR1-D 63361
|
57กซ66
|
18.5
|
30
|
37
|
37
|
55
|
LC1-D04กข50กข60
|
|
LR1-D 80363
|
63กซ80
|
22
|
33กซ37
|
40กซ45
|
40กซ45
|
59กซ63
|
LC1-D80
|
|
